Specification:
- Scale: 1/10
- Ground Clearance: 70mm?chassis?, 35mm(axle)
- Wheelbase: 380mm
- Length: 660mm
- Width: 232mm
- Height: 270mm
- Wheel(diameter/width): 110/36mm
- Drive Mode: Front-Wheel Drive + 4WD
- Gear Ratio/Low speed 36:1(F), 38:1(R)
- Gear Ratio/High speed: 19:1(F), 20:1(R)
- Front-Rear Speed Ratio: 6.80%
- Motor/ pinion: 6235-RC550-35T?/17T
- Gears: All Steel
- Ramp Angle: 23°
- Approach Angle: 48.5°
- Departure Angle: 36.6°
- Number of Servos: 6P
- Steering Servo: Digit Metal Gear 30KG
- Winch Servo: 360° Digit Metal Gear 25KG
- Function Servo: 4.8~7.4V/9G (gear/lock)
- Winch steel cable: 0.8 diameter/90CM
- ESC: “Hobbywing” WP-1060/60A
- Radio/Rx: 2.4G/10CH
- Bodyshell Type: PC soft
- Bodyshell Colors: Sky Gray, Dune Yellow
- Recommended Battery (exclude): 2S-3S Lipo
- Car Weight (excluding battery): 4.44KG with two spare tires
